Image is for your reference only,please check specifications for details
- LM2901DR2G - ON Semiconductor
-
Manufacturer:ON Semiconductor
-
ManyChip's Part#:MC161295
-
Category:Comparator, Analog Comparator IC
-
Package:SOIC-14
-
Datasheet:Datasheet 3D Model
-
Description:Analogue Comparator, General Purpose, 4, 1.3µs, 3V to 36V, SOIC, 14Pins
-
Stock Locations:
-
Availability:9,000 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.2
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- This comparator is designed for use in level detection, low-level sensing and memory applications in consumer automotive and industrial electronic applications.
- Features
- ---
- |
- Single or Split Supply Operation
- Low Input Bias Current: 25 nA (Typ)
- Low Input Offset Current: +/- 5.0 nA (Typ)
- Input Common Mode Voltage Range to Gnd
- Low Output Saturation Voltage: 130 mV (Typ) @ 4.0 mA
- TTL and CMOS Compatible
- ESD Clamps on the Inputs Increase Reliability without Affecting Device Operation
LM2901DR2G Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | SOIC-14 |
| Supply Voltage (DC) | 36.0 V |
| Operating Voltage | 2V ~ 36V |
| Halogen Free Status | Halogen Free |
| Output Current | 16mA @5V |
| Supply Current | 2 mA |
| Number of Circuits | 4 Circuit |
| Number of Channels | 4 Channel |
| Number of Positions | 14 Position |
| Power Dissipation | 1000 W |
| Quiescent Current | 800 µA |
| Input Offset Voltage | 7 mV |
| Input Bias Current | 250 nA |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 1000 mW |
| Supply Voltage | 3V ~ 36V |
| Supply Voltage (Max) | 36 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Size-Length | 8.75 mm |
| Size-Width | 4 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | -40℃ ~ 105℃ |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
