Description
- LQH55D series are winding type coils for choke by using high performance thick wire wound technology. Features 1. Low direct current resistance, large current capacity and large inductance 2. For DC-DC converters and DC power supply circuits
LQH55DN222M03L Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package | 2220 |
| Current Rating | 100 mA |
| Capacitance Tolerance | ±20 % |
| Inductance | 2.2 mH |
| Self Resonant Frequency | 1.2 MHz |
| Part Family | LQH |
| Resistance | 21.5 Ω |
| Resonant Frequency | 1.20 MHz |
| Inductance Tolerance | ±20 % |
| Test Frequency | 10 kHz |
| DC Resistance (DCR) | ≤30.1 Ω |
| Current Rating (DC) | 100 mA |
| Operating Temperature (Max) | 80 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Resistance (DC Max) | 21.5 Ω |
| Show | |
| Size-Length | 5.7 mm |
| Size-Width | 6 mm |
| Size-Height | 5 mm |
| Weight | 0.48 g |
| Operating Temperature | -40℃ ~ 80℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| Minimum Packing Quantity | 350 |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
