Description
- Features 1. Low direct current resistance, large current capacity and large inductance 2. High density mounting 3. For DC-DC converters and DC power supply circuits
LQH66SN101M03L Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Case/Package | 2525 |
| Current Rating | 520 mA |
| Capacitance Tolerance | ±20 % |
| Inductance | 100 µH |
| Self Resonant Frequency | 6.5 MHz |
| Part Family | LQH |
| Resistance | 360 mΩ |
| Inductance Tolerance | ±20 % |
| Test Frequency | 100 kHz |
| DC Resistance (DCR) | ≤504 mΩ |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Resistance (DC Max) | 360 mΩ |
| Show | |
| Size-Length | 6.3 mm |
| Size-Width | 6.3 mm |
| Size-Height | 4.7 mm |
| Weight | 0.71 g |
| Operating Temperature | -40℃ ~ 80℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| Minimum Packing Quantity | 350 |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
