Description

DESCRIPTION
The LT ®1399 and LT1399HV contain three independent 300MHz current feedback amplifiers, each with a shutdown pin. The LT1399HV is a higher voltage version of the LT1399. The LT1398 is a two amplifier version of the LT1399.
The LT1398/LT1399 operate on all supplies from a single 4V to ±6V. The LT1399HV operates on all supplies from 4V to ±7.5V.
Each amplifier draws 4.6mA when active. When disabled each amplifier draws zero supply current and its output be comes high impedance. The amplifiers turn on in only 30ns and turn off in 40ns, making them ideal in spread spectrum and portable equipment applications.
FEATURES
■ 300MHz Bandwidth on ±5V (AV = 1, 2 and –1)
■ 0.1dB Gain Flatness: 150MHz (AV = 1, 2 and –1)
■ Completely Off in Shutdown, 0µA Supply Current
■ High Slew Rate: 800V/µs
■ Wide Supply Range:
±2V(4V) to ±6V(12V) (LT1398/LT1399)
±2V (4V) to ±7.5V (15V) (LT1399HV)
■ 80mA Output Current
■ Low Supply Current: 4.6mA/Amplifier
■ Fast Turn-On Time: 30ns
■ Fast Turn-Off Time: 40ns
■ 16-Pin Narrow SO/Narrow SSOP Packages
APPLICATIONS
■ RGB Cable Drivers
■ LCD Drivers
■ Spread Spectrum Amplifiers
■ MUX Amplifiers
■ Composite Video Cable Drivers
■ Portable Equipment
