Description

General Description
The MAX4310–MAX4315 single-supply mux-amps combine high-speed operation, low-glitch switching, and
excellent video specifications. The six products in this family are differentiated by the number of multiplexer
inputs and the gain configuration.
Features
♦Single-Supply Operation Down to +4V
♦345MHz -3dB Bandwidth (MAX4311)
150MHz -3dB Bandwidth (MAX4313)
♦540V/µs Slew Rate (MAX4313)
♦Low 6.1mA Quiescent Supply Current
♦40ns Channel Switching Time
♦Ultra-Low 10mVp-p Switching Transient
♦0.06%/0.08° Differential Gain/Phase Error
♦Rail-to-Rail Outputs: Drives 150Ωto within 730mV of the Rails
♦Input Common-Mode Range Includes Negative Rail
♦Low-Power Shutdown Mode
♦Available in Space-Saving 8-Pin µMAX and 16-Pin QSOP Packages
Applications
Video Signal Multiplexing
Video Crosspoint Switching
Flash ADC Input Buffers
75ΩVideo Cable Drivers
High-Speed Signal Processing
Broadcast Video
Medical Imaging
Multimedia Products

Show

MAX4315ESE Specifications
