Description
- High-Side Gate Driver IC Non-Inverting 18-PDIP
MAX620CPN Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 18 Pin |
| Case/Package | PDIP-18 |
| Supply Voltage (DC) | 16.5V (max) |
| Rise/Fall Time | 1.7µs, 2.5µs |
| Number of Outputs | 4 Output |
| Power Dissipation | 640 mW |
| Rise Time | 1700 ns |
| Output Current (Max) | 0.025 A |
| Fall Time | 2500 ns |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Supply Voltage | 4.5V ~ 16.5V |
| Supply Voltage (Min) | 4.5 V |
| Show | |
| Operating Temperature | 0℃ ~ 70℃ (TA) |
| Product Lifecycle Status | Unknown |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
