Image is for your reference only,please check specifications for details

MAX9933 - Maxim Integrated
Manufacturer:
Maxim Integrated
ManyChip's Part#:
MC481505886
RoHS:
Lead free / RoHS Compliant
Datasheet:
Datasheet 3D Model
Description:
2MHz to 1.6GHz 45dB RF-Detecting Controllers and RF Detector2MHz to 1.6GHz, 45dB RF-Detecting Controllers Simplify Control-Loop Design of Power Amplifiers and TIAs
Stock Locations:
Availability:
233 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

General Description
The MAX9930–MAX9933 low-cost, low-power logarithmic amplifiers are designed to control RF power amplifiers (PA) and transimpedance amplifiers (TIA), and to detect RF power levels. These devices are designed to operate in the 2MHz to 1.6GHz frequency range.
Features
♦Complete RF-Detecting PA Controllers(MAX9930/MAX9931/MAX9932)
♦Complete RF Detector (MAX9933)
♦Variety of Input Ranges
MAX9930/MAX9933: -58dBV to -13dBV(-45dBm to 0dBm for 50ΩTermination)
MAX9931: -48dBV to -3dBV (-35dBm to +10dBm for 50ΩTermination)
MAX9932: -43dBV to +2dBV (-30dBm to +15dBm for 50ΩTermination)
♦2MHz to 1.6GHz Frequency Range
♦Temperature Stable Linear-in-dB Response
♦Fast Response: 70ns 10dB Step
♦10mA Output Sourcing Capability
♦Low Power: 17mW at 3V (typ)
♦13µA (typ) Shutdown Current
♦Available in a Small 8-Pin µMAX Package
Applications
RSSI for Fiber Modules, GPON-CATV Triplexors
Low-Frequency RF OOK and ASK Applications
Transmitter Power Measurement and Control
TSI for Wireless Terminal Devices
Cellular Handsets (TDMA, CDMA, GPRS, GSM)

Show

MAX9933 Specifications
