Description

The MC78L05ACP is a 3-terminal 0.1A Positive Voltage Regulator for applications that required supply current up to 100mA. This product is general usage and suitable for many different applications.
Thermal overload protection
Short-circuit current limiting
Output voltage offered in ±5% tolerance

Show

MC78L05ACP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-226-3
Power Rating	0.75 W
Number of Outputs	1 Output
Input Voltage (DC)	30.0V (max)
Output Voltage	5 V
Output Current	100 mA
Number of Positions	3 Position
Power Dissipation	750 W
Quiescent Current	5.5 mA
voltage rating	1.7V @40mA
Input Voltage (Max)	30 V
Output Current (Max)	100 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	750 mW
Accuracy	±5 %
Input Voltage	≤30 V
	Show
Size-Length	5.2 mm
Size-Width	4.19 mm
Size-Height	5.33 mm
Operating Temperature	0℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
