Description

The MPSA13G is a NPN bipolar Darlington Transistor, designed for use in switching applications, such as print hammer, relay, solenoid and lamp drivers. Simplified circuit design and reduces component count.
Reduced board space
Simplifies circuit design
Reduces component count

Show

MPSA13G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-226-3
Voltage Rating (DC)	30.0 V
Current Rating	500 mA
Output Voltage	30 V
Output Current	500 mA
Number of Positions	3 Position
Polarity	NPN
Power Dissipation	625 mW
Breakdown Voltage (Collector to Emitter)	30 V
Continuous Collector Current	0.5A
hFE Min	10000 @100mA, 5V
Input Power (Max)	625 mW
DC Current Gain (hFE)	10000
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Gain Bandwidth	125MHz (Min)
Power Dissipation (Max)	625 mW
Input Voltage	10 V
	Show
Size-Length	5.2 mm
Size-Width	4.19 mm
Size-Height	5.33 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
