MPZ2012S300AT000 - TDK
Manufacturer:
TDK
ManyChip's Part#:
MC1707500
Category:
Ferrite
Package:
0805
Datasheet:
Datasheet 3D Model
Description:
30Ω Impedance Ferrite Bead 0805 (2012 Metric) Surface Mount Power Line 6A 1 Lines 10mOhm Max DCR -55℃ ~ 125℃
Stock Locations:
Availability:
1,898 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.04

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TDK MPZ 2012 series are chip ferrite beads used for automobiles and power supply circuits. They are convenient components which exert effects as noise suppression measures by simply being inserted into circuits in series unlike bypass capacitors. Multilayer integration monolithic structure makes it highly reliable and has low direct current resistance for compatibility with large currents. Typical applications are engine control units, powertrains and car multimedia (telematics).
EIA 2012 standard chip size
Impedance values at 100MHz is 120 ohm
Operating temperature range of -55°C to 125°C

Show

MPZ2012S300AT000 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package (SI)	2012
Case/Package	0805
Current Rating	6 A
Resistance	0.01 Ω
Test Frequency	100 MHz
DC Resistance (DCR)	≤10.00 mΩ
Current Rating (Max)	6 A
Current Rating (DC)	6 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Resistance (DC Max)	0.01 Ω
	Show
Size-Length	0.079 in
Size-Width	0.049 in
Size-Height	1.05 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
Minimum Packing Quantity	4000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
