Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Case/Package | Metal |
Number of Contacts | 5 Contact |
Gender | Male |
Contact Plating | Gold |
Voltage Rating (DC) | 50.0 V |
Voltage Rating (AC) | 50.0 V |
Current Rating | 3 A |
Insulation Resistance | 1000 MΩ |
Number of Positions | 5 Position |
Number of Mating Cycles | 1000 Cycle |
Current Rating (Max) | 3A/触头 |
Operating Temperature (Max) | 80 ℃ |
Operating Temperature (Min) | -30 ℃ |
Voltage Rating (Max) | 50 V |
Voltage Rating | 50 V |
Maximum Contact Resistance (Max) | 5 mΩ |
Show | |
Size-Height | 25 mm |
Color | Black |
Contact Material | Brass |
Operating Temperature | -30℃ ~ 80℃ |
Product Lifecycle Status | Active |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/12/17 |
HTS Code | 8536694040 |
ECCN Code | EAR99 |
