Description

Dealing with high voltages and currents? Protect your circuit with the high side NCP330MUTBG power switch, developed by ON Semiconductor. This charge controller has single output. This charge controller has an input voltage of 1.8 to 5.5 V. This device has a maximum power dissipation of 580 mW. It features 0.026 Ohm switch on resistance. Its maximum power dissipation is 580 mW. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This charge controller has an operating temperature range of -40 °C to 85 °C.

Show

NCP330MUTBG Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	4 Pin
Case/Package	UDFN-4
Power Rating	0.225 W
Halogen Free Status	Halogen Free
Number of Outputs	1 Output
Input Voltage (DC)	5.00 V
Output Current	3 A
Number of Positions	4 Position
Power Dissipation	0.58 W
Rise Time	2 ms
Input Voltage (Min)	1.8 V
Output Current (Max)	3 A
Output Current (Min)	3 A
Fall Time	4 ms
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	580 mW
Input Voltage	5 V
	Show
Size-Length	1.2 mm
Size-Width	1.6 mm
Size-Height	0.5 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
