Description

The NCS3S4805SC is an isolated 4:1 input single-output DC/DC Converter offers a single output voltage from input voltage range of 12V. The device is housed with a standard pin-out. It also offers operating temperature range -40 to 85°C with derating.
No electrolytic capacitors
Continuous short circuit protection
1.5kVDC Isolation hi pot test
5% Maximum load
80% Typical efficiency
75mVp-p Typical ripple and noise
1.1ms Start-up time

Show

NCS3S4805SC Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	6 Pin
Case/Package	DIP-8
Power Rating	3 W
Number of Outputs	1 Output
Output Voltage	5 V
Output Current	0.6 A
Output Power	3 W
Isolation Voltage	1.5 kV
Input Voltage (Max)	75 V
Input Voltage (Min)	18 V
Input Voltage (DC Max)	75 V
Input Voltage (DC Min)	18 v
Output Current (Max)	600 mA
Input Current (Min)	153 mA
Input Power (Max)	3 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	18V ~ 75V
	Show
Size-Length	21.95 mm
Size-Width	9.45 mm
Size-Height	11.25 mm
Weight	4.4 g
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
