Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 16 Pin |
Case/Package | DIP-16 |
Frequency | 24 MHz |
Digital Logic Level | CMOS |
Supply Voltage (DC) | 15.0 V, 18.0 V (max) |
Number of Outputs | 1 Output |
Output Current | 6.8 mA |
Number of Circuits | 2 Circuit |
Number of Channels | 2 Channel |
Number of Positions | 16 Position |
Clock Speed | 24 MHz |
Number of Bits | 2 Bit |
Polarity | Non-Inverting, Inverting |
Voltage Nodes | 5.00 V, 10.0 V, 15.0 V |
Power Dissipation | 500 mW |
Number of Gates | 2 Gate |
Input Capacitance | 5 pF |
Number of Inputs | 2 Input |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -55 ℃ |
Supply Voltage | 3V ~ 18V |
Supply Voltage (Max) | 18 V |
Supply Voltage (Min) | 3 V |
Show | |
Size-Length | 19.3 mm |
Size-Width | 6.35 mm |
Size-Height | 4.57 mm |
Operating Temperature | -55℃ ~ 125℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2014/12/17 |
ECCN Code | EAR99 |
