- LPC812M101JTB16X - NXP
-
Manufacturer:NXP
-
ManyChip's Part#:MC42698941
-
Category:Microcontroller, MCU IC
-
Package:XSON-16
-
Datasheet:Datasheet 3D Model
-
Description:MCU 32Bit ARM Cortex M0+ RISC 16KB Flash 3.3V 16Pin XSON T/R
-
Stock Locations:
-
Availability:252 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.28
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Overview
- The LPC81x MCU family provides an optimal entry point into the low-cost LPC800 series. This family balances a range of versatile timing, connectivity, and analog peripherals while delivering it in a low pin count easy to use package. Unique to this price level, this family provides three select peripherals to ease transition into the 32-bit space. The switch matrix provides designers the flexibility to map pins accordingly to simplify component routing on a PCB. Another unique ability of this family comes through the use of the SCTimer, which can be configured to generate a variety of timing or PWM waveforms without the intervention from the CPU. To simplify serial communication requirements, the pattern match engine can be configured to generate interrupts from user configurable Boolean operations on its 8 pins.
- The LPC800 series shares critical pinouts through the range of subfamilies and packages and customers can easily swap or scale packages and subfamilies as their needs change. The LPC83x family builds on the functionality of the LPC81x by increasing its flash size and adding a 12-bit ADC with sample rates of up to 1.2 Msps.
- MoreLess
- ## Features
- LPC81x and LPC83x MCUs are ideal for:
- * Sensor gateways
- * Communications interface for wireless protocols such as NFC, BTLE, Zigbee or WiFi
- * Human machine interface (HMI) tasks such as touch, gesture, swipe
- * Battery powered devices
- * Space constrained designs
- * Simple protocol bridging
- * Replacement of 8/16-bit applications
- ## Features
LPC812M101JTB16X Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Number of Pins | 16 Pin |
| Case/Package | XSON-16 |
| Frequency | 30 MHz |
| Number of Positions | 16 Position |
| RAM Memory Size | 4 KB |
| Number of Bits | 32 Bit |
| Number of Inputs and Outputs | 14 Input IO |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 1.8V ~ 3.6V |
| Supply Voltage (Max) | 3.6 V |
| Supply Voltage (Min) | 1.8 V |
| Show | |
| Operating Temperature | -40℃ ~ 105℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
