NFE31PT222Z1E9L - muRata
Manufacturer:
muRata
ManyChip's Part#:
MC91821
Category:
RFI Shielding
Package:
1206
Datasheet:
Datasheet 3D Model
Description:
LC (T-Type) EMI Filter 3rd Order Low Pass 1Channel C = 2200pF 6A 1206 (3216 Metric), 3 PC Pad
Stock Locations:
Availability:
3,181 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.12

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The NFE31PT series from Murata are universal type (power lines/signal lines) chip EMIFIL EMI suppression filters. These are small size T-type LC circuit filter with built-in ferrite bead. NFE31PT series meets large current, good high frequency performance because of its feed through structure. The structure incorporates built-in ferrite beads which minimize resonance with surrounding circuits. Its large rated current of 6A and low voltage drop due to small DC resistance are suitable for DC power line use.
EIA 1206 size code
22pF to 2,200pF lineups can be used in signal lines
Rated voltage of 25VDC
Operating temperature range -40°C to +85°C
Minimum insulation resistance is 1000Mohm

Show

NFE31PT222Z1E9L Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package (SI)	3216
Case/Package	1206
Voltage Rating (DC)	25.0 V
Current Rating	6 A
Insulation Resistance	≥1000 MΩ
Capacitance	2200 pF
Capacitance Tolerance	±50 %
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Shielding	No
Current Rating (Max)	6 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating (Max)	25 VDC
Voltage Rating	25 V
	Show
Size-Length	3.2 mm
Size-Width	1.6 mm
Size-Height	1.6 mm
Dielectric Material	Ceramic
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
