Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 15 Pin |
Case/Package | Multiwatt-15 |
Supply Voltage (DC) | 35.0V (max) |
Output Current | 5 A |
Number of Circuits | 2 Circuit |
Number of Channels | 1 Channel |
Number of Positions | 15 Position |
Power Dissipation | 50000 mW |
Quiescent Current | 30.0 mA |
Output Power | 60 W |
Gain | 80 dB |
Input Offset Voltage | 10 mV |
Input Bias Current | 500 nA |
Output Current (Max) | 5000 mA |
Operating Temperature (Max) | 70 ℃ |
Operating Temperature (Min) | 0 ℃ |
Power Dissipation (Max) | 50000 mW |
Show | |
Size-Length | 19.6 mm |
Size-Width | 5 mm |
Size-Height | 10.7 mm |
Operating Temperature | 0℃ ~ 70℃ (TA) |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance | No SVHC |
REACH SVHC Compliance Edition | 2015/12/17 |
ECCN Code | EAR99 |
