Image is for your reference only,please check specifications for details
Updated at 29/10/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The IRLML6401TRPBF is a -12V single P-channel HEXFET Power MOSFET, compatible with existing surface mount techniques. This MOSFET features increased reliability and easier manufacturing.
- Halogen-free
- MSL1, Industrial qualification
- Multi-vendor compatibility
- Environmentally-friendly
- Trench MOSFET technology
- ±8V Gate to source voltage
- 0.01W/°C Linear derating factor
IRLML6401TRPBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-23-3 |
| Power Rating | 1.3 W |
| Number of Positions | 3 Position |
| Drain to Source Resistance (on) (Rds) | 0.05 Ω |
| Polarity | P-Channel |
| Power Dissipation | 1.3 W |
| Threshold Voltage | 550 mV |
| Input Capacitance | 830 pF |
| Drain to Source Voltage (Vds) | 12 V |
| Continuous Drain Current (Ids) | 4.3A |
| Rise Time | 32 ns |
| Input Capacitance (Ciss) | 830pF @10V(Vds) |
| Input Power (Max) | 1.3 W |
| Fall Time | 210 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 1.3W (Ta) |
| Show | |
| Size-Length | 3.04 mm |
| Size-Width | 1.4 mm |
| Size-Height | 1.02 mm |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/12/17 |
