Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 4 Pin |
Case/Package | 4-Mini-Flat |
Rise/Fall Time | 4µs, 3µs |
Input Voltage (DC) | 1.20 V |
Output Voltage | ≤80.0 V |
Number of Circuits | 1 Circuit |
Number of Channels | 1 Channel |
Forward Voltage | 1.2 V |
Power Dissipation | 170 mW |
Rise Time | 4 µs |
Isolation Voltage | 3750 Vrms |
Breakdown Voltage (Collector to Emitter) | 80 V |
Forward Current | 50 mA |
Output Voltage (Max) | 80 V |
Input Current (Min) | 50 mA |
Reverse Breakdown Voltage | 6 V |
Maximum Forward Voltage (Max) | 1.4 V |
Forward Current (Max) | 50 mA |
Fall Time | 3 µs |
Fall Time (Max) | 18 µs |
Fall Time (Max) | 18 µs |
Operating Temperature (Max) | 100 ℃ |
Operating Temperature (Min) | -30 ℃ |
Power Dissipation (Max) | 170 mW |
Show | |
Size-Length | 4.4 mm |
Size-Width | 3.6 mm |
Size-Height | 2.6 mm |
Operating Temperature | -30℃ ~ 100℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
