Description

The NMH0515SC is a 2-output board-mount isolated DC to DC Converter for on-board point-of-use power systems. The NMH series 2W industrial temperature range DC/DC converter is standard building block that is ideally suited for providing dual rail supplies on single rail boards with the added benefit of galvanic isolation to reduce circuit noise. All of the rated power may be drawn from a single pin provided the total load does not exceed 2watts. Pin compatibility with the NMA 1watt series ensures minimal effort in upgrading distributed power systems.
Efficiency up to 86%
1.44W/cm³ Power density
No heatsink required
Footprint from 1.46cm²
Industry standard pinout
Power sharing on output
1kVDC Isolation
Internal SMD construction
Fully encapsulated with toroidal magnetics
No external components required
MTTF up to 1.5 million hours
No electrolytic or tantalum capacitors
-40 to +85°C Operating temperature range

Show

NMH0515SC Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	SIP-7
Supply Voltage (DC)	5.00 V
Power Rating	2 W
Number of Outputs	2 Output
Input Voltage (DC)	4.50V ~ 5.50V
Output Voltage	±15 V
Output Current	67.0 mA
Flammability Rating	UL 94 V-0
Output Power	2 W
Isolation Voltage	1 kV
Input Voltage (Max)	5.5 V
Input Voltage (Min)	4.5 V
Input Voltage (DC Max)	5.5 V
Input Voltage (DC Min)	4.5 v
Output Current (Max)	67mA, 67mA
Input Power (Max)	2 W
Input Power (Max)	2 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	4.5V ~ 5.5V
	Show
Size-Length	19.5 mm
Size-Width	7.5 mm
Size-Height	10 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Compliant with Exemption
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
