Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 2 Pin |
Case/Package | SOD-123 |
Halogen Free Status | Halogen Free |
Number of Positions | 2 Position |
Forward Voltage | 450mV @700mA |
Forward Current | 1 A |
Max Forward Surge Current (Ifsm) | 5.5 A |
Maximum Forward Voltage (Max) | 450 mV |
Forward Current (Max) | 1 A |
Operating Temperature (Max) | 125 ℃ |
Operating Temperature (Min) | -65 ℃ |
Show | |
Size-Length | 2.84 mm |
Size-Width | 1.8 mm |
Size-Height | 1.25 mm |
Operating Temperature | -65℃ ~ 125℃ |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
