Description

Reduce the overall cost and complexity of your power management system by implementing this NUD3160LT1G specialized power IC from ON Semiconductor to automate general tasks and functions. This USB PWM controller has a minimum operating temperature of -40 °C and a maximum of 125 °C.

Show

NUD3160LT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Supply Voltage (DC)	60.0V (max)
Halogen Free Status	Halogen Free
Number of Outputs	1 Output
Output Voltage	61.0 V
Output Current	200 mA
Number of Positions	3 Position
Power Dissipation	0.225 W
Drain to Source Voltage (Vds)	60.0 V
Continuous Drain Current (Ids)	150 mA
Rise Time	618 ns
Output Current (Max)	150 mA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	225 mW
Supply Voltage (Max)	60 V
	Show
Size-Length	3.04 mm
Size-Width	1.4 mm
Size-Height	1.01 mm
Operating Temperature	-40℃ ~ 125℃ (TA)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
