Description

Even low voltage discharges can cause damage to electronic components so get this diode array NUP4114HMR6T1G ESD protection device from ON Semiconductor for added protection. This device"s maximum clamping voltage is 10 V. This ESD diode has a maximum ESD protection device voltage of ±15@Air Gap/±8@Contact Disc kV. This ESD diode has a minimum operating temperature of -40 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It is made in a quad configuration.

Show

NUP4114HMR6T1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	6 Pin
Case/Package	TSOT-23-6
Operating Voltage	5.5 V
Capacitance	0.6 pF
Halogen Free Status	Halogen Free
Breakdown Voltage	6 V
Number of Positions	6 Position
Clamping Voltage	10 V
Test Current	1 mA
Min Breakdown Voltage	5.5 V
Reverse Breakdown Voltage	6 V
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
	Show
Size-Length	1.6 mm
Size-Width	1.6 mm
Size-Height	0.5 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
