Description
- The PMZB290UNE2 is a N-channel enhancement-mode FET in a leadless ultra-small surface-mount plastic package using Trench MOSFET technology. It is suitable for use in relay driver, high-speed line driver, low-side load-switch and switching circuit applications.
- Low threshold voltage
- Very fast switching
- >2kV HBM ESD protection
- Ultra-thin package profile of 0.37mm
- -55 to 150°C Junction temperature range
PMZB290UNE2YL Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | DFN1006B-3 |
| Number of Channels | 1 Channel |
| Number of Positions | 3 Position |
| Drain to Source Resistance (on) (Rds) | 270 mΩ |
| Power Dissipation | 715 mW |
| Threshold Voltage | 450 mV |
| Input Capacitance | 46 pF |
| Drain to Source Voltage (Vds) | 20 V |
| Breakdown Voltage (Drain to Source) | 20 V |
| Rise Time | 10 ns |
| Input Capacitance (Ciss) | 46pF @10V(Vds) |
| Input Power (Max) | 350 mW |
| Fall Time | 4 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | 55 ℃ |
| Power Dissipation (Max) | 350mW (Ta), 5.43W (Tc) |
| Show | |
| Operating Temperature | -55℃ ~ 150℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
