Description
- Provide the ability to switch between voltages by using this non-inverting|inverting|step up|step down PTH08T240FAD DC to DC converter and switching regulator module. It has a voltage of 0.69 to 5.5 V. This part has a temperature range of -40 °C to 85 °C. The component will be shipped in tray format.
PTH08T240FAD Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 11 Pin |
| Case/Package | DIP-11 |
| Supply Voltage (DC) | 5.00 V |
| Power Rating | 20 W |
| Number of Outputs | 1 Output |
| Input Voltage (DC) | 4.50V ~ 14.0V |
| Output Voltage | 0.69V ~ 5.5V |
| Output Current | 10 A |
| Number of Regulated Outputs | 1 Output |
| Switching Frequency | 260kHz ~ 340kHz |
| Topology | Buck |
| Input Voltage (Max) | 14 V |
| Input Voltage (Min) | 4.5 V |
| Output Voltage (Max) | 2 V |
| Output Voltage (Min) | 0.69 V |
| Output Current (Max) | 10 A |
| Output Current (Min) | 0 A |
| Input Power (Max) | 20 W |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 4.5V ~ 14V |
| Show | |
| Size-Length | 22.1 mm |
| Size-Width | 15.75 mm |
| Size-Height | 8.5 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
