Description

The SCT2280KEC is a 1200V N-channel Silicon Power MOSFET with fast switching speed and low on resistance. Suitable for solar inverters, DC/DC converters, SMPS, induction heating and motor drives.
Fast reverse recovery
Easy to parallel
Simple drive requirement

Show

SCT2280KEC Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-247-3
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.28 Ω
Polarity	N-Channel
Power Dissipation	108 W
Threshold Voltage	4 V
Drain to Source Voltage (Vds)	1200 V
Continuous Drain Current (Ids)	14A
Rise Time	19 ns
Input Capacitance (Ciss)	667pF @800V(Vds)
Input Power (Max)	108 W
Fall Time	29 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	108W (Tc)
	Show
Size-Length	20.95 mm
Size-Width	15.9 mm
Size-Height	5.03 mm
Operating Temperature	175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
