SN65LVDT388ADBT - TI
Manufacturer:
TI
ManyChip's Part#:
MC21356192
Category:
Interface IC, Interface Controller
Package:
TSSOP-38
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS SN65LVDT388ADBT Differential Line Receiver IC, 630Mbps Data Rate, 8 Receivers, 15kV ESD, 3V to 3.6V, TSSOP-38
Stock Locations:
Availability:
289 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 9.96

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The SN65LVDT388ADBT is an octal differential Line Receiver implements the electrical characteristics of low-voltage differential signalling (LVDS). This signalling technique lowers the output voltage levels of 5V differential standard levels (such as EIA/TIA-422B) to reduce the power, increase the switching speeds and allow operation with a 3V supply rail. Any of the differential receivers provides a valid logical output state with a ±100mV differential input voltage within the input common-mode voltage range. The input common-mode voltage range allows 1V of ground potential difference between two LVDS nodes. Additionally, the high-speed switching of LVDS signals almost always requires the use of a line impedance matching resistor at the receiving end of the cable or transmission media. The LVDT products eliminate this external resistor by integrating it with the receiver.
Open-circuit failsafe
Flow-through pin-out
Integrated 110R line termination resistors on LVDT products
Bus-terminal ESD exceeds 15kV
2.6ns Typical propagation delay time
100ps Typical output skew
<1ns Part-to-part skew
630Mbps Signalling rate
Green product and no Sb/Br

Show

SN65LVDT388ADBT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	38 Pin
Case/Package	TSSOP-38
Supply Voltage (DC)	3.00V (min)
Supply Current	40 mA
Number of Positions	38 Position
Power Dissipation	1071 W
Data Rate	630 Mbps
Input Current (Min)	40 μA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1071 mW
Supply Voltage	3V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	3 V
	Show
Size-Length	9.7 mm
Size-Width	4.4 mm
Size-Height	1.15 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
