Description
- Amplify analog and digital signals by driving the input to the transmission line with this SN7406NSR buffer and line driver from Texas Instruments. With an open collector output, this is power management at its best. This line driver has an operating temperature range of 0 °C to 70 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. It has 6 channels per chip. This inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.75 V, while its maximum is 5.25 V.
SN7406NSR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | SOP-14 |
| Supply Voltage (DC) | 4.75V ~ 5.25V |
| Number of Outputs | 6 Output |
| Number of Circuits | 6 Circuit |
| Number of Channels | 6 Channel |
| Number of Bits | 6 Bit |
| Propagation Delay Max (tpd) | 23.0 ns |
| Voltage Nodes | 5.00 V |
| Quiescent Current | 32.0 mA |
| Number of Gates | 6 Gate |
| Number of Inputs | 6 Input |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Supply Voltage | 4.75V ~ 5.25V |
| Supply Voltage (Max) | 5.25 V |
| Supply Voltage (Min) | 4.75 V |
| Show | |
| Size-Length | 10.3 mm |
| Size-Width | 5.3 mm |
| Size-Height | 1.85 mm |
| Operating Temperature | 0℃ ~ 70℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
