- SN74AHCT16240DGVR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC98849372
-
Category:Logic Control, Logic Gate IC
-
Package:TVSOP-48
-
Datasheet:Datasheet 3D Model
-
Description:16Bit Buffers/Drivers With 3-State Outputs 48-TVSOP -40℃ to 85℃
-
Stock Locations:
-
Availability:203 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.42
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The "AHCT16240 devices are 16-bit buffers and line drivers designed specifically to improve the performance and density of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters.
- These devices can be used as four 4-bit buffers, two 8-bit buffers, or one 16-bit buffer. They provide inverting outputs and symmetrical active-low output-enable (OE\\\\) inputs.
- To ensure the high-impedance state during power up or power down, OE\ should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.
- The SN54AHCT16240 is characterized for operation over the full military temperature range of -55°C to 125°C. The SN74AHCT16240 is characterized for operation from -40°C to 85°C.
SN74AHCT16240DGVR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 48 Pin |
| Case/Package | TVSOP-48 |
| Supply Voltage (DC) | 4.50V ~ 5.50V |
| Number of Outputs | 16 Output |
| Number of Circuits | 4 Circuit |
| Number of Channels | 16 Channel |
| Number of Bits | 16 Bit |
| Propagation Delay Max (tpd) | 9.50 ns |
| Voltage Nodes | 5.00 V |
| Output Current Drive | -1.00 mA |
| Number of Inputs | 4 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | 40 ℃ |
| Supply Voltage | 4.5V ~ 5.5V |
| Supply Voltage (Max) | 5.5 V |
| Supply Voltage (Min) | 4.5 V |
| Show | |
| Size-Length | 9.7 mm |
| Size-Width | 4.4 mm |
| Size-Height | 1.05 mm |
| Operating Temperature | -40℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
