Image is for your reference only,please check specifications for details
- SSL1D03BD - Schneider Electric
-
Manufacturer:Schneider Electric
-
ManyChip's Part#:MC98113671
-
Category:Solid State Relay
-
Datasheet:Datasheet 3D Model
-
Description:SCHNEIDER ELECTRIC SSL1D03BD Solid State Relay, SPST-NO, 3.5A, PCB, Through Hole, 1VDC, 24VDC
-
Stock Locations:
-
Availability:156 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 16.42
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- **Zelio SSL Solid State Slim Relays**
- Schneider Electric Zelio solid state relays provide a compact and innovative solution for a wide variety of applications with interfacing control and load switching. The slim SSL series are available with several input and output configurations for both AC and DC switching applications. Compact size and modular design reduces space and allows easy mounting on the socket. SSL series plug-in type relays can be mounted directly on a PCB or DIN Rail mounted with a socket. DIN Rail sockets are available in screw connector or spring terminal types.
SSL1D03BD Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Operating Voltage | 24.0V (max) |
| Capacitance | 1.5 pF |
| Contacts Type | SPST-NO |
| Load Current | 3.5 A |
| Load Current (Max) | 3.5 A |
| Load Current (Min) | 0.001 A |
| Operating Voltage (Min) | 1 VDC |
| Operating Voltage (Max) | 24 VDC |
| Show | |
| Size-Length | 28 mm |
| Size-Height | 15 mm |
| Operating Temperature | -20℃ ~ 80℃ |
| Packaging | Tube |
| RoHS | RoHS Compliant |
