SSM2211SZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC179030
Category:
Audio Amplifier IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES SSM2211SZ Audio Power Amplifier, AB, 1Channel, 1.5W, 2.7V to 5.5V, SOIC, 8Pins
Stock Locations:
Availability:
284 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 2.38

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The SSM2211SZ is a Low Distortion Audio Power Amplifier that delivers 1Wrms of low distortion audio power into a bridge connected 8R speaker load (or 1.5Wrms into a 4R load). It operates over a wide temperature range and is specified for single-supply voltages between 2.7 and 5.5V. When operating from batteries, it continues to operate down to 1.75V. This makes the SSM2211 best choice for unregulated applications, such as toys and games. Featuring a 4MHz bandwidth and distortion below 0.2% THD + N at 1W, superior performance is delivered at higher power or lower speaker load impedance than competitive units. The low differential DC output voltage results in negligible losses in the speaker winding and makes high value DC blocking capacitors unnecessary. The battery life is extended by using shutdown mode, which typically reduces quiescent current drain to 100nA. Applications include personal portable computers, hands-free telephones and transceivers, talking toys, intercom systems.
1.5W Output with THD + N <1%
Differential bridge-tied load output
Single-supply operation
Functions down to 1.75V
Wide bandwidth (4MHz)
Highly stable phase margin (>80°)
Low distortion (0.2% THD + N at 1W output)
Excellent power supply rejection
ESD sensitive device, take proper precaution while handling the device.

Show

SSM2211SZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	6.00 V
Power Rating	1.5 W
Supply Current	9.5 mA
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	65.0 dB
Quiescent Current	9.50 mA
Bandwidth	4 MHz
Gain Bandwidth Product	4 MHz
Output Power	1.5 W
Gain	40 dB
Input Offset Voltage	0.2 mV
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-20 ℃
Power Dissipation (Max)	633 mW
Supply Voltage	2.7V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
