Image is for your reference only,please check specifications for details

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

N-Channel 650V 3.8A (Ta), 22.5A (Tc) 2.8W (Ta), 160W (Tc) Surface Mount PowerFLAT™ (8x8)

Show

STL45N65M5 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	5 Pin
Case/Package	PowerFLAT-8
Polarity	N-CH
Power Dissipation	2.8 W
Threshold Voltage	4 V
Drain to Source Voltage (Vds)	650 V
Continuous Drain Current (Ids)	22.5A
Input Capacitance (Ciss)	3470pF @100V(Vds)
Operating Temperature (Max)	150 ℃
Power Dissipation (Max)	2.8W (Ta), 160W (Tc)
	Show
Size-Length	8 mm
Size-Width	8 mm
Size-Height	0.95 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
