STPS10H100CFP - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC3197143
Category:
Schottky Diode
Package:
TO-220-3
Datasheet:
Datasheet 3D Model
Description:
Schottky Rectifier, 100V, 5A, Dual Common Cathode, TO-220FP, 3Pins, 610mV
Stock Locations:
Availability:
3,756 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.57

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The STPS10H100CFP is a high-voltage power Schottky Rectifier designed for high-frequency miniature switched mode power supplies such as adapters and onboard DC/DC converters.
High junction temperature capability for converters located in confined environment
Low leakage current at high-temperature
Low static and dynamic losses as a result of the Schottky barrier
Avalanche capability specified

Show

STPS10H100CFP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Voltage Rating (DC)	100 V
Current Rating	10.0 A
Output Current	≤10.0 A
Number of Positions	3 Position
Forward Voltage	0.85 V
Polarity	Standard
Forward Current	5 A
Max Forward Surge Current (Ifsm)	180 A
Maximum Forward Voltage (Max)	610 mV
Forward Current (Max)	10 A
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	175℃ (Max)
	Show
Size-Length	10.4 mm
Size-Width	4.6 mm
Size-Height	9.3 mm
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
