Description

The STPS80170CW is a high-voltage dual centre-tab Schottky Power Rectifier suitable for high frequency switched mode power supplies. This device is intended for use to enhance the reliability of the application.
High junction temperature capability
Low leakage current
Good trade-off between leakage current and forward-voltage drop
Low thermal resistance
High frequency operation
Avalanche specification

Show

STPS80170CW Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-247-3
Voltage Rating (DC)	170 V
Current Rating	80.0 A
Number of Positions	3 Position
Forward Voltage	840mV @40A
Forward Current	40 A
Max Forward Surge Current (Ifsm)	500 A
Maximum Forward Voltage (Max)	840 mV
Forward Current (Max)	80 A
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-65 ℃
Junction Temperature	175℃ (Max)
Junction Temperature (Max)	175 ℃
	Show
Size-Length	15.75 mm
Size-Width	5.15 mm
Size-Height	20.15 mm
Operating Temperature	-65℃ ~ 175℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	ECL99
