Description

The STTH20002TV1 is a Turbo 2 ultrafast High Voltage Rectifier features high surge current capability, very low forward losses and low recovery time. This dual rectifier is suitable for welding equipment, high power industrial application and secondary rectification of the applications.
170A RMS forward voltage

Show

STTH20002TV1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	ISOTOP
Voltage Rating (DC)	200 V
Current Rating	160 A
Forward Voltage	1.05V @100A
Reverse recovery time	50 ns
Forward Current	120 A
Max Forward Surge Current (Ifsm)	1 kA
Maximum Forward Voltage (Max)	1.2 V
Forward Current (Max)	120 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Junction Temperature	150℃ (Max)
Junction Temperature (Max)	150 ℃
	Show
Size-Length	38.2 mm
Size-Width	25.5 mm
Size-Height	9.1 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	EAR99
