- 2-Input NAND Gate
- Features
- • High Speed : tpd = 7ns (Typ.) at VCC = 5 V
- • Low power dissipation : ICC = 1 μA (Max) at Ta = 25°C
- • High noise immunity : VNIH = VNIL = 28% VCC (min)
- • Output drive capability : 5 LSTTL Loads
- • Symmetrical Output Impedance : |IOH| = IOL= 2mA (min)
- • Balanced propagation delays : tpLH ≒ tpHL
- • Wide operating voltage range : VCC = 2 to 6 V
TC7S00F Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 5 Pin |
| Case/Package | SSOP-5 |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Show | |
| Size-Length | 2.9 mm |
| Size-Width | 1.6 mm |
| Size-Height | 1.1 mm |
| Product Lifecycle Status | Obsolete |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
