Description

The TD62001P / AP / F / AF Series are high−voltage, high−current darlington drivers comprised of seven NPN darlington pairs. All units feature integral clamp diodes for switching inductive loads.
Applications include relay, hammer, lamp and display (LED) drivers.
FEATURES
Output current (single output) 500 mA MAX.
High sustaining voltage output
35 V MIN. (TD62001P / F Series)
50 V MIN. (TD62001AP / AF Series)
Output clamp diodes
Inputs compatible with various types of logic
Package Type−P, AP : DIP−16 pin
Package Type−F, AF : SOP−16 pin

Show

TD62004AP Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	PDIP
Polarity	NPN
Breakdown Voltage (Collector to Emitter)	50 V
Continuous Collector Current	0.5A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1470 mW
	Show
Product Lifecycle Status	Obsolete
RoHS	Non-Compliant
