TDA7293HS - ST Microelectronics
Manufacturer:
ST Microelectronics
ManyChip's Part#:
MC14198804
Category:
Audio Amplifier IC
Package:
Multiwatt-15
Datasheet:
Datasheet 3D Model
Description:
STMICROELECTRONICS TDA7293HS Audio Power Amplifier, AB, 1Channel, 100W, ± 12V to ± 50V, Multiwatt, 15Pins
Stock Locations:
Availability:
325 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 10.23

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TDA7293HS is a DMOS Audio Amplifier with mute and standby. The built-in muting function with turn-on delay simplifies the remote operation avoiding on-off switching noises. Parallel mode is possible by connecting several devices and using pin11. High output power can be delivered to very low impedance loads, so optimizing the thermal dissipation of the system.
Multipower BCD technology
Very high operating voltage range (±50V)
DMOS power stage
Muting and stand-by functions
No switch ON/OFF noise
Very low distortion
Very low noise
Short-circuit protection
Thermal shutdown
Clip detector
Modularity
ESD sensitive device, take proper precaution while handling the device.

Show

TDA7293HS Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	15 Pin
Case/Package	Multiwatt-15
Supply Voltage (DC)	60.0 V
Input Voltage (DC)	90.0 V
Output Current	10 A
Number of Circuits	2 Circuit
Number of Channels	1 Channel
Number of Positions	15 Position
Power Dissipation	50 W
Output Power	100 W
Gain	80 dB
Input Offset Voltage	10 mV
Input Bias Current	1000 nA
Output Current (Max)	10000 mA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	50000 mW
	Show
Size-Length	20.2 mm
Size-Width	17.75 mm
Size-Height	5 mm
Operating Temperature	0℃ ~ 70℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
