Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Actively measure temperature with this TFPT0603L1001FV thermistor from Vishay. This part has a temperature range of -55 °C to 125 °C. It has 2 terminals. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This product is 1.6 mm long, 0.45 mm tall and 0.85 mm deep.
TFPT0603L1001FV Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 2 Pin |
| Case/Package (SI) | 1608 |
| Case/Package | 0603 |
| Operating Voltage | 30.0V (max) |
| Capacitance Tolerance | ±1 % |
| Power Rating | 75.0 mW |
| Power Dissipation | 75.0 mW |
| Resistance | 1000 Ω |
| Resistance Tolerance | ±1 % |
| Input Power (Max) | 75 mW |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Voltage Rating (Max) | 30 V |
| Operating Voltage (Max) | 30 V |
| Show | |
| Size-Length | 1.6 mm |
| Size-Width | 0.8 mm |
| Size-Height | 0.45 mm |
| Operating Temperature | -55℃ ~ 150℃ |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
