GENERAL DESCRIPTION
The AD688 is a high precision ±10 V tracking reference. Low tracking error, low initial error, and low temperature drift give the AD688 reference absolute ±10 V accuracy performance previously unavailable in monolithic form. The AD688 uses a proprietary ion-implanted buried Zener diode, and laser wafer drift trimming of high stability thin-film resistors to provide outstanding performance.
FEATURES
±10 V tracking outputs
Kelvin connections
Low tracking error: 1.5 mV
Low initial error: 2.0 mV
Low drift: 1.5 ppm/°C
Low noise: 6 μV p-p
Flexible output force and sense terminals
High impedance ground sense
Wide body SOIC and CERDIP packages

Show

AD688AQ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	CDIP-16
Capacitance Tolerance	±0.05 %
Input Voltage (DC)	12.0V ~ 36.0V
Output Voltage	±10 V
Output Current	10 mA
Supply Current	12 mA
Number of Channels	2 Channel
Number of Positions	16 Position
Input Voltage (Max)	36 V
Output Voltage (Max)	10 V
Output Current (Max)	10 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	10 V
Input Voltage	12V ~ 38V
	Show
Size-Length	21.34 mm
Size-Width	7.87 mm
Size-Height	3.56 mm
Operating Temperature	-40℃ ~ 85℃
Temperature Coefficient	±3 ppm/℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
