Description

The VNI4140K is a quad high-side smart power Solid State Relay made using STMicroelectronics VIPower technology and intended to drive four independent resistive or inductive loads with one side connected to ground. Active current limitation avoids dropping the system power supply in case of shorted load. Built-in thermal shutdown protects the chip from over-temperature and short-circuits. In over-load conditions, channel turns OFF and back ON automatically so to maintain junction temperature between TTSD and TR. If this condition makes case temperature reach TCSD, over-loaded channel is turned OFF and restart only when case temperature has decreased down to TCR. In case of more than one channel in overload, restart of the over-loaded channels is not simultaneous and in order to avoid high peak current from the supply. Non-over-loaded channels continue operating normally. The open drain diagnostics outputs indicate over-temperature conditions.
Shorted load protections
Junction over-temperature protection
Protection against loss of ground
Current limitation
Under-voltage shutdown
Open-drain diagnostic outputs
3.3V CMOS/TTL compatible inputs
Fast demagnetization of inductive loads
ESD sensitive device, take proper precaution while handling the device.

Show

VNI4140K Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	PowerSSO-24
Supply Voltage (DC)	10.5V (min)
Number of Outputs	4 Output
Output Current	700 mA
Supply Current	2.4 mA
Number of Positions	24 Position
Input Voltage (Max)	41 V
Output Current (Max)	700 mA
Output Current (Min)	0.7 A
Number of Inputs	4 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	36 V
Supply Voltage (Min)	10.5 V
Input Voltage	10.5V ~ 36V
	Show
Size-Length	10.5 mm
Size-Width	7.6 mm
Size-Height	2.4 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
