Description

Are you in search of a pulse-width modulation controller? Look no further than ON Semiconductor"s TL494BDR2G voltage mode PWM controller. Its typical operating supply voltage is 15 V. This voltage mode driver supports push-pull topology. Its 2 PWM outputs produce a current of 500 mA. It has a switching frequency of 200 kHz. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device has a typical operating supply voltage of 15 V. Its minimum operating supply voltage of 7 V, while its maximum is 40 V. This voltage mode driver"s maximum duty cycle is 48(Typ) %. This voltage mode driver has an operating temperature range of -40 °C to 125 °C.

Show

TL494BDR2G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Frequency	40 kHz
Number of Outputs	2 Output
Output Current	500 mA
Number of Positions	16 Position
Power Dissipation	1000 mW
Rise Time	100 ns
Switching Frequency	200 kHz
Topology	Flyback, Forward, Half-Bridge, Push-Pull, Step-Up, Step-Down
Thermal Resistance	80 ℃/W
Duty Cycle	50 %
Maximum Duty Cycle	48 %
Fall Time	40 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1000 mW
Supply Voltage	7V ~ 40V
Supply Voltage (Max)	40 V
Supply Voltage (Min)	7 V
	Show
Size-Length	10 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99
