TLE4284DVATMA1 - Infineon
Manufacturer:
Infineon
ManyChip's Part#:
MC47620800
Category:
Voltage Regulator
Package:
TO-252-3
Datasheet:
Datasheet 3D Model
Description:
INFINEON TLE4284DVATMA1 LDO Voltage Regulator, Adjustable, 3.2V to 40V in, 1.3V drop, 1A out, TO-252-3
Stock Locations:
Availability:
226 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.06

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TLE4284DV is a monolithic integrated NPN type Voltage Regulator that can supply loads up to 1A. It is designed to supply microprocessor systems or other loads under the severe conditions of automotive applications and therefore it is equipped with additional protection against overload, short circuit and overtemperature. An input voltage VI in the range of <VI <40V is regulated to VQ. The dropout voltage VDR ranges from 1.1 to 1.4V depending on the load current level.
Short circuit protection
Overtemperature protection
Adjustable output voltage

Show

TLE4284DVATMA1 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	TO-252-3
Number of Outputs	1 Output
Output Current	1 A
Number of Positions	3 Position
Quiescent Current	1000 µA
voltage rating	1.3 V
Input Voltage (Max)	40 V
Input Voltage (Min)	3.2 V
Output Current (Max)	1 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	3.0 %
Operating Voltage (Max)	40.0 V
Input Voltage	≤40 V
	Show
Size-Length	6.5 mm
Size-Width	2.3 mm
Size-Height	6.22 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
