Description

* 2.7 V to 24 V supply voltage operation * Operation from unregulated power supply * High sensitivity and high stability of the magnetic switching points * High resistance to mechanical stress by Active Error Compensation * Reverse battery protection (-18 V) * Superior temperature stability * Peak temperatures up to 195°C without damage * Low jitter (typ. 1 μs) * Digital output signals * Bipolar version * Excellent matching between the 2 Hall probes * Hall plate distance 1.45 mm * Direction & speed information * Direction signal switches before the speed signal

Show

TLE4966L Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	P-SSO-3-2
Supply Voltage (DC)	2.70V (min)
Power Rating	0.072 W
Output Voltage	18 V
Output Current	10 mA
Supply Current	7 mA
Number of Positions	4 Position
Power Dissipation	72 mW
Output Current (Max)	10 mA
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.7V ~ 18V
Supply Voltage (Max)	18 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	5.34 mm
Size-Width	1 mm
Size-Height	3.38 mm
Operating Temperature	-40℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
