Image is for your reference only,please check specifications for details
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The TLV320AIC3007IRSBT is a low power stereo Audio Codec with stereo headphone amplifier and mono class-D speaker driver, as well as multiple inputs and outputs programmable in single-ended or fully differential configurations. Extensive register-based power control is included, enabling stereo 48kHz DAC playback as low as 15mW from a 3.3V analog supply. The record path of the TLV320AIC3007 contains integrated microphone bias, digitally controlled stereo microphone preamplifier and automatic gain control (AGC), with mix/mux capability among the multiple analog inputs. Programmable filters are available during record which can remove audible noise that can occur during optical zooming in digital cameras. The playback path includes mix/mux capability from the stereo DAC and selected inputs, through programmable volume controls, to the various outputs. It contains three high-power output drivers as well as two single-ended line output drivers and a differential class-D output driver.
- Stereo codec with integrated mono Class-D amplifier
- High performance audio DAC
- Flexible power saving modes and performance are available
- High performance audio ADC
- Capability for floating input configurations
- Single-ended stereo line outputs
- Ultralow power mode with passive analog bypass
- Programmable input/output analog gains
- Automatic gain control (AGC) for record
- Programmable microphone bias level
- Programmable PLL for flexible clock generation
- I²C Control bus
- Green product and no Sb/Br
- Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
TLV320AIC3007IRSBT Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 40 Pin |
| Case/Package | WQFN-40 |
| Number of Channels | 12 Channel |
| Number of Positions | 40 Position |
| Power Dissipation | 2350 mW |
| Sample Rate | 96 KSPS |
| Power Consumption | 15.0 mW |
| Bandwidth | 20 kHz |
| Number of ADCs | 2 ADC |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 2350 mW |
| Number of Input Channels | 7 Channel |
| Number of Output Channels | 6 Channel |
| Number of DACs | 2 DAC |
| Show | |
| Size-Length | 5.15 mm |
| Size-Width | 5.15 mm |
| Size-Height | 0.75 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
| ECCN Code | EAR99 |
