TPA1517DWPR - TI
Manufacturer:
TI
ManyChip's Part#:
MC22549517
Category:
Audio Amplifier IC
RoHS:
Lead free / RoHS Compliant
Datasheet:
Datasheet 3D Model
Description:
TEXAS INSTRUMENTS TPA1517DWPR Audio Power Amplifier, AB, 2Channel, 6W, 9.5V to 18V, SOIC, 20Pins
Stock Locations:
Availability:
800 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 6.24

Updated at 02/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TPA1517 is a stereo audio power amplifier that contains two identical amplifiers capable of delivering 6 W per channel of continuous average power into a 4- load at 10% THD+N or 5 W per channel at 1% THD+N. The gain of each channel is fixed at 20 dB. The amplifier features a mute/standby function for power-sensitive applications. The amplifier is available in the PowerPAD 20-pin surface-mount thermally-enhanced package (DWP) that reduces board space and facilitates automated assembly while maintaining exceptional thermal characteristics. It is also available in the 20-pin thermally enhanced DIP package (NE).

Show

TPA1517DWPR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SOIC-20
Supply Voltage (DC)	18.0 V
Supply Current	70 mA
Number of Circuits	1 Circuit
Number of Channels	2 Channel
Number of Positions	20 Position
Power Dissipation	2.94 W
Quiescent Current	45.0 mA
Output Power	6 W
Gain	20 dB
Output Current (Max)	4000 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	2940 mW
Supply Voltage	9.5V ~ 18V
	Show
Size-Height	2.55 mm
Operating Temperature	-40℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
