Description
- When your circuit needs protection from any voltage spikes be sure to use this voltage detector TPS3803G15DCKR voltage monitor IC from Texas Instruments. This device has a maximum power dissipation of 321 mW. Its typical operating supply voltage is 1.5 V. Its maximum power dissipation is 321 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device has a typical operating supply voltage of 1.5 V. Its minimum operating supply voltage of 1.3 V, while its maximum is 6 V. This voltage supervisor IC has an operating temperature range of -40 °C to 85 °C. It has a typical reset threshold voltage of Adj|1.4 V, with a minimum of Adj|1.379 V and a maximum of Adj|1.421 V.
TPS3803G15DCKR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 5 Pin |
| Case/Package | SC-70-5 |
| Supply Voltage (DC) | 1.30V (min) |
| Supply Current | 0.006 mA |
| Power Dissipation | 0.321 W |
| Quiescent Current | 3.00 µA |
| Threshold Voltage | 1.4 V |
| Reset Threshold Voltage (Min) | 1.379 V |
| Reset Threshold Voltage (Max) | 1.421 V |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 321 mW |
| Accuracy | ±1.5 % |
| Show | |
| Size-Length | 2 mm |
| Size-Width | 1.25 mm |
| Size-Height | 0.9 mm |
| Operating Temperature | -40℃ ~ 85℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
