TPS62300DRCR - TI
Manufacturer:
TI
ManyChip's Part#:
MC19371675
Category:
DC to DC Converter
Package:
VSON-10
Datasheet:
Datasheet 3D Model
Description:
Step-Down Regulator Adjustable, 500mA, 3MHz Step-Down Converter in QFN or Chip-Scale Conv DC-DC 2.7V to 6V Synchronous Step Down Single-Out 0.6V to 5.4V 0.5A 10Pin VSON EP T/R
Stock Locations:
Availability:
9,573 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.25

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TPS62300DRCR is a high-frequency synchronous step-down DC-to-DC Converter optimized for battery-powered portable applications. Intended for low-power applications, the TPS623xx supports up to 500mA load current and allows the use of tiny, chip inductor and capacitors. The device is ideal for mobile phones and similar portable applications powered by a single-cell Li-ion battery or by 3-cell NiMH/NiCd batteries. With an output voltage range from 5.4V down to 0.6V, the device supports the low-voltage TMS320 DSP family, processors in smart-phones and PDAs as well as notebooks. The TPS62300 operates at 3MHz fixed switching frequency and enters the power-save mode operation at light load currents to maintain high efficiency over the entire load current range. For low noise applications, the device can be forced into fixed frequency PWM mode by pulling the MODE/SYNC pin high. The device can also be synchronized to an external clock signal in the range of 3MHz.
Best in class load and line transient
Complete 1mm component profile solution
Power-save mode operation at light load currents
Fixed and adjustable output voltage
100% Duty cycle for lowest dropout
Synchronizable on the fly to external clock signal
Up to 93% efficiency at 3MHz operation
-0.5%/+1.3% PWM DC voltage accuracy over temperature
35ns Minimum on-time
86µA Quiescent current
Green product and no Sb/Br

Show

TPS62300DRCR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	VSON-10
Number of Outputs	1 Output
Output Voltage	0.6V ~ 5.4V
Output Current	500 mA
Number of Positions	10 Position
Quiescent Current	86.0 µA
Number of Regulated Outputs	1 Output
Switching Frequency	3 MHz
Topology	Buck
Input Voltage (Max)	6 V
Input Voltage (Min)	2.7 V
Output Voltage (Max)	5.4 V
Output Voltage (Min)	600 mV
Output Current (Max)	0.5 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.7 V
Supply Voltage (Min)	2.7 V
Input Voltage	2.7V ~ 6V
	Show
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
