Image is for your reference only,please check specifications for details

TVX1V222MCD - Nichicon
Manufacturer:
Nichicon
ManyChip's Part#:
MC13416520
Category:
Aluminum Electrolytic Capacitors, Aluminum Capacitors, Capacitors Aluminum
Package:
Axial, Can
Datasheet:
Datasheet 3D Model
Description:
Cap Aluminum Lytic 2200uF 35V 20% (16 X 31.5mm) Axial 1580mA 2000H 85℃
Stock Locations:
Availability:
236 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.86

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The TVX1V222MCD is a standard aluminium Electrolytic Capacitor with axial leaded termination and suitable for general purposes. Printed with white colour letter on purple blue sleeve marking.
Anti-solvent (through 100V only)
1580mA RMS at 85°C/120Hz Rated ripple current

Show

TVX1V222MCD Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Case/Package	Axial, Can
Voltage Rating (DC)	35.0 V
Operating Voltage	35 VDC
Capacitance	2200 µF
Capacitance Tolerance	±20 %
Ripple Current	1580 mA
Ripple Current (Low Frequency)	1.58A @120Hz
Ripple Current (High Frequency)	1.817A @10kHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	35 V
	Show
Size-Length	31.5 mm
Size-Height	31.5 mm
Size-Diameter	16.0 mm
Lead Length	35.0 mm
Dielectric Material	Aluminum Electrolytic
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
Life (Hours)	2000h @85℃
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
