Image is for your reference only,please check specifications for details
- VEML6070 - Vishay Semiconductor
-
Manufacturer:Vishay Semiconductor
-
ManyChip's Part#:MC18976963
-
Category:Optical Sensor
-
Package:OPLGA-6
-
Datasheet:Datasheet 3D Model
-
Description:VISHAY VEML6070 UV Light Sensor, VEML6070, Digital, 16Bit, I2C, 2.7VDC to 5.5VDC
-
Stock Locations:
-
Availability:322 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.06
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The VEML6070 is an advanced ultraviolet Light Sensor with I²C protocol interface and designed by the CMOS process. It is easily operated via a simple I²C command. The active acknowledge (ACK) feature with threshold windows setting allows the UV sensor to send out an UVI alert message. Under a strong solar UVI condition, the smart ACK signal can be easily implemented by the software programming. This light sensors incorporates a photodiode, amplifiers and analog/digital circuits into a single chip. Adoption of Filtron™ UV technology provides the best spectral sensitivity to cover UV spectrum sensing. It has an excellent temperature compensation and a robust refresh rate setting that does not use an external RC low pass filter. VEML6070 has linear sensitivity to solar UV light and is easily adjusted by an external resistor. Software shutdown mode is provided, which reduces power consumption to be less than 1µA.
- Converts solar UV light intensity to digital data
- Excellent temperature compensation
- High dynamic detection resolution
- Support acknowledge feature
VEML6070 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 6 Pin |
| Case/Package | OPLGA-6 |
| Supply Current | 100 µA |
| Number of Channels | 1 Channel |
| Wavelength | 335 nm |
| Peak Wavelength | 355 nm |
| Rise Time | 1000 ns |
| Fall Time | 300 ns |
| Fall Time (Max) | 300 ns |
| Fall Time (Max) | 1000 ns |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage | 2.7V ~ 5.5V |
| Show | |
| Size-Length | 2.35 mm |
| Size-Width | 1.8 mm |
| Size-Height | 1 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
